HITEC X1 Pro DC/DC Multi-Charger - Manual (Page 45)

45
The battery/charger connections (red/black)
are reversed.
The battery connection has been discon-
nected.
The battery connection is wrong.
The balance connection is wrong.
The input voltage is less than 11V.
The input voltage is higher than 18V.
The voltage of one cell in the battery pack is
too low.
The voltage of one cell in the battery pack is
too high.
The voltage of one cell in the battery pack is
invalid.
The cell count is wrong.
The internal temperature of the charger is too
high.
The external temperature of the charger is
too high.
WarnInGs and error MessaGes
REVERSE POLARITY
CONNECTION BREAK
CONNECT ERROR
ChECK MAIN PORT
BALANCE CONNECT
ERROR
DC IN TOO LOW
DC IN TOO hIGh
CELL ERROR
LOW VOLTAGE
CELL ERROR
hIGh VOLTAGE
CELL ERROR
VOLTAGE INVALID
CELL NUMBER
INCORRECT
INT. TEMP.TOO
hIGh
ExT. TEMP.TOO
hIGh
