Page 28
AILERON
(Check in "Auto Balance Mode" )
RIGHT Roll the plane , the right aileron should automatically move downwards,
while the left aileron move up.
LEFT Roll the plane , the left aileron should automatically move downwards,
while the right aileron should move up.
If the servo movement is incorrect, you need to reverse the automated servo
movement please select ―AIL REV‖.
Upward
Roll right
Downward
Upward
Downwar
d
Roll left
ELEVATOR
(Check in "Auto Balance Mode" )
UPWARD Incline the plane nose ,the elevator should automatically move
downwards.
DOWNWARD incline the nose ,levator should automatically move upwards.
If the servo movement is incorrect, you need to reverse the automated servo
movement please select “ELE REV”.
Downward
Upward
Nose Up
Nose Down
