FeiYu Tech FY-Panda2 Autopilot User Manual
Page 14
Guilin Feiyu Electronic Technology Co., Ltd.
Guilin Feiyu Electronic Technology Co., Ltd http://www.feiyu-tech.com [email protected]
Page 13
Vibration
absorbing
pads
(dampers),use for Panda Ⅱ vibration
damping installation.
2*5P RC receiver connecting wires,
use for connect the RC receiver and
Remote Adaptor, the wires is arranged
by the colors.
Yellow
——AIL;
White (bundled with red & black)
——ELE;
Orange
——THR;
Green
——RUD;
White
——CH5;
Red
——CH6;
Blue
——CH7;
Brown
——CH8
The wire connection about Remote
Adaptor and FY-602 Data radio.
The wire connection about Remote
Adaptor and USB data cable.
Attention:
You must use the 4P
crosswire like picture left shows, when
you connect the USB data cable and
FY-602 data radio.
