8.5 Airspeed Sensor Module Installation
The airspeed sensor need to pull ahead the front of the pneumatic opening and in
the line with the direction of flight. You can install the Airspeed sensor to the wing or in
the front of the nose, do not block the front of the air inlet , we can use the glue to fix the
airspeed sensor.
Note: Make sure that after installation, the fuselage in flight airflow can not
interfere with air intakes.
8.6 Camera Installation
The P1 port of the autopilot module output a camera shutter triggered signals, this
signal is TTL level(0-3V),but you need to do the camera transformation, open the camera
and release the Camera Remote Cord. The picture below show the transformation of
Canon S100V.
