Page 14
Arrow Forward (Default Direction)
Arrow Towards To Left Arrow Towards To Right
Arrow Towards To Back
Nose of the plane
8. The Installation Of Main Module
8.1 PandaⅡ Module Installation
The Autopilot module must be placed horizontally and as close as possible to the
plane‘s CG (Center of Gravity). The default direction is the arrow direction must be
pointing towards the nose of the plane (i.e. direction of flight). You can change the
direction to four directions via the GCS software, i.e direction forward, back, left, right
(shown below) .
When installing the autopilot module please make use of the supplied damper mount
or other DIY vibration damping device, especially on gasoline aircraft. Otherwise the
vibrations will cause a large data inconsistencies which will adversely affect the autopilot
accuracy.
