Page 18
10. RC Setting, SW1&SW2 Channel Setting
PandaⅡ requires a minimum of 6-channel RC receiver.4 Receiver channels are
used for aileron (channel 1), elevator (channel 2)
，throttle (channel 3) and rudder
(channel 4) signal output. 2 free Receiver channels are required to control the PandaⅡ
Flight Modes (a 3- position switch or dial knob, ‖SW1‖) and Autopilot Mode (a 3-position
switch or dial knob, ‖SW2‖).
RC mode Setting of your controller has to be fixed wing mode and cancel all mix
control setting.
PandaⅡ need two 3-position-switch to control the flight mode. One SW1 used for
setting manual mode, stabilized mode and 3D mode, another one SW2 used for setting
Auto Return To Launch Mode and Waypoint Navigation Flight Mode(default) or Auto
Circling Mode and Fixed altitude & Heading lock Mode(Need to setup through the setting
software).
After set up switch mode, you can through switch to the corresponding position then
according to LED flashing situation to confirm whether the setting is correct or not. the
details please see"Pnada2 indicator light instruction"
SW1&SW2 default setting:
11. FY-GCS 5.1 Ground Control Software Manual
FYGCS 5.1 is the ground control station software for Feiyu autopilot system. The
main features include (but not limited to): Electronic mapping, Telemetry data monitoring
of flight parameters , flight attitude , flight speed , altimeter , location, Recording and
playback of telemetry data into Ground Station Computer , Route editing , Map
loading ,etc .
SW1 SW2
Manual Mode Waypoint Navigation Mode
Stabilized Mode NULL
3D Mode Return To Launch Mode
