Features & Components
ExpressCard Slot 2 - 7
2
ExpressCard Slot
The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/
34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC
Cards).
ExpressCard/54 is used for applications
which require a larger interface slot, e.g.
CompactFlash card reader. The number de-
notes the card width; 54mm for the Express
Card/54 and 34mm for the ExpressCard/34.
Make sure you install the Card Reader driv-
er (see
).
Inserting and Removing
ExpressCards
• Align the ExpressCard with the slot and
push it in until it locks into place.
• To remove an ExpressCard, simply
press the card to eject it.
ExpressCard Slot
Cover
Make sure you keep the
cover in the Express-
Card slot when not in
use. This will help pre-
vent foreign objects and/
or dust getting in to the
ExpressCard Slot.
Figure 2 - 5
Left View
1.
ExpressCard
Slot
1
1
