1 - 6 System Map: Front View
Quick Start Guide
1
System Map: Front View
Figure 1 - 2 - Front View
5
1
4
1.
Built-In PC Camera
2.
PC Camera LED
3.
Built-In Microphone
4.
LCD (With Optional Touch Panel for
Windows 7 OS)
5.
Power & System Activity LED Indicators
6.
Function Buttons*
7.
Power Button*
8.
RJ-45 LAN Jack
9.
2 * USB Ports
10. eSATA Port
11. External Monitor Port
12. 2 * COM Ports
13. DC-In Jack
6
7
5
*Note the power and function buttons are located
along the bottom underside of the LCD
9
8
12
12
13
