i. LON 100 Internet Server Programmer’s Reference 12-11
SET_STATE >100.0 0xFF 0
SET_STATE <=100.0 (setting value) 0
SET_NUL N/A 0xFF 0
12.2.1.2.1.8 SNVT_state_TO_16xSNVT_switch
Use this Type Translator Rule to translate a data point of type SNVT_state to multiple
output data points of type SNVT_switch. When you use this rule, you must reference the
SNVT_state input data point that is to be translated by its in the
element.
The 16 SNVT_switch data points to store the result of the translation are signified by a list of
elements in the parameter. Each element must contain two
properties: and . The must identify a
SNVT_switch data point. The must be in the range 0-15.
Each output data point will be assigned a value based on its index number, and the value of
the corresponding field in the input data point. For example, the output data point using
index number 0 within the Type Translator will be assigned a value based on Bit0 of the
input data point. The output data point using index number 7 within the Type Translator
will be assigned a value based on Bit6 of the input data point, and so on.
If the value of a BitX field is 0, then the applicable SNVT_switch data point will be assigned
the value 0.0 0. If the value of a BitX field is 1, then the applicable SNVT_switch data point
will be assigned the value 100.0 1.
12.2.1.2.1.9 SNVT_switch_TO_SNVT_lev_disc
Use this Type Translator Rule to translate an input data point of type SNVT_switch to an
output data point of type SNVT_lev_disc. When you use this rule, you must reference the
SNVT_switch input data point that is to be translated by its in the
element. You must reference the SNVT_lev_disc data point to store the result
of the translation by its in the element.
The SNVT_lev_disc output data point will be assigned an enumeration based on the value of
the state and value fields of the input data point each time a translation is made. The value
assigned to the output data point follow the rules described in Table 68.
Table 68 SNVT_switch_TO_SNVT_lev_disc
If the SNVT_switch Input Field Values Are....
State value
Then the SNVT_lev_disc Output Data Point Will
Be Set To...
0 N/A ST_OFF
1 0.0 ST_OFF
1 1.0-25.0 ST_LOW
1 26.0-50.0 ST_MED
1 51.0-75.0 ST_HIGH
1 76.0-100.0 ST_ON
1 >100.0 ST_NUL
