i. LON 100 Internet Server Programmer’s Reference 12-9
Table 63 SNVT_lev_disc_TO_SNVT_switch
If the Input SNVT_lev_disc Data Point Is..... Then the SNVT_switch Output Data Point
Will Be Set To...
ST_NUL 0xff 0
ST_OFF 0.0 0
ST_ON 100.0 1
ST_HIGH 75.0 1
ST_LOW 50.0 1
ST_MED 25.0 1
12.2.1.2.1.4 SNVT_occupancy_TO_SNVT_setting
Use this Type Translator Rule to translate an input data point of type SNVT_occupancy to
an output data point of type SNVT_setting. When you use this rule, you must reference the
SNVT_occupancy data point that is to be translated by its in the
element. You must reference the SNVT_setting data point that will store the
result of the translation by its in the element.
Each time a translation is made, the three fields of the SNVT_setting data point (function,
rotation, setting) will be assigned different values based on enumeration currently assigned
to the input data point. These values assigned to these fields follow the rules described in
Table 64.
Table 64 SNVT_occupancy_TO_SNVT_setting
Then the SNVT_setting Output Field Values Will Be Set To… If the SNVT_occupancy
Input Data Point Is…. function Setting Rotation
OC_NUL SET_NUL 0 0.0
OC_UNOCCUPIED SET_STATE 60 -80.01
OC_OCCUPIED SET_STATE 100 80.24
OC_BYPASS SET_STATE 100.0 80.24
OC_STANDBY SET_STATE 60.2 -40.0
12.2.1.2.1.5 SNVT_scene_TO_SNVT_setting
Use this Type Translator Rule to translate an input data point of type SNVT_scene to an
output data point of type SNVT_setting. When you use this rule, you must reference the
SNVT_scene data point that is to be translated by its in the
element. You must reference the SNVT_setting data point to store the result
of the translation by its in the element.
Each time a translation is made, the three fields of the SNVT_setting data output point
(function, rotation, setting) will be assigned different values based on the values of the
function and scene_number fields of the SNVT_scene data point. The values assigned to the
fields of the output data point follow the rules described in Table 65.
Table 65 SNVT_scene_TO_SNVT_setting
If the SNVT_scene Input Field Values
Are….
Then the SNVT_setting Output Field Values Are….
function scene_number function setting Rotation
SC_RECALL 0 SET_STATE 0 0
SC_RECALL 1 SET_STATE 25 0
