Specifications - 208
JT60/JT60 All Terrain Operator’s Manual
All Terrain Pipe U.S. Metric
Length, without inner pipe (per SAE J2022) 171 in 4.3 m
Joint diameter (per SAE J2022) 4.13 in 105 mm
Tubing diameter (per SAE J2022) 3.63 in 92 mm
Minimum bend radius 205 ft 63 m
Weight, with inner pipe (per SAE J2022) 264 lb 120 kg
Pipe box weight
large AT pipe box with 18 pipe 5580 lb 2530 kg
small AT pipe box with 9 pipe 3150 lb 1430 kg
Power Pipe Forged U.S. Metric
Length (per SAE J2022) 180 in 4.57 m
Joint diameter (per SAE J2022) 3.25 in 83 mm
Tubing diameter (per SAE J2022) 2.88 in 73 mm
Minimum bend radius 169 ft 52 m
Weight (per SAE J2022) 180 lb 82 kg
Pipe box weight
large JT pipe box with 28 pipe 5984 lb 2715 kg
small JT pipe box with 16 pipe 3548 lb 1610 kg
