Pipe Boxes
7. Load a pipe in auxiliary pipe loaders and rest it against pipe stop.
8. Move at least 10’ away from the machine.
9. Move auxiliary pipe loaders under row 4 (row 3 if using AT pipe).
10. Raise pipe into row 4.
11. Move shuttles all the way out.
12. Repeat steps 8-12 to load more pieces of pipe into row 4.
13. Move pipe to pipeloader grippers.
• Raise last pipe into row 4.
• Move shuttles out.
• Lower pipe into front grippers.
14. Before operating pipeloader:
• Close both auxiliary pipe loaders.
• Remove pipe stop and store it on drill frame.
• Step away from drilling unit.
Crushing weight. If load falls or moves it could kill or crush you. Use
proper procedures and equipment or stay away.
To help avoid injury:
• have enough people on hand to manually add or remove single pipe to pipe box.
• move 10’ away from machine after pipe is placed in auxiliary pipe loaders.
