JT60/JT60 All Terrain Operator’s Manual
Service - 199
As Needed
Change Auto Lubricator TJC Pail
Check pipe auto lubricator TJC level and change
pail as needed.
To change pail:
1. Remove wingnuts and bolts attaching base
ring (4) to pail cover (1).
2. Rotate base ring slightly to clear hooks on
cover and remove pail from cover.
3. Remove follower plate (3) from empty pail and
install into new pail. Press firmly on follower
plate until TJC comes up in center opening.
4. Remove base ring from empty pail and install
onto new pail.
5. Install pail into place over pump dip tube. Use hooks on cover to support base ring.
6. Install bolts and wingnuts.
7. Remove cap (2) from discharge tee on pump. Operate pump until discharged TJC is free of air
pockets. Replace cap.
IMPORTANT: Use only genuine Ditch Witch tool joint compound to maintain warranty. See
“Recommended Lubricants/Service Key” on page 170 for more information.
j40om030w.eps
1
2 3
4
