JT60/JT60 All Terrain Operator’s Manual
Systems and Equipment - 125
Electric Strike System
Troubleshoot Strike System
When strike system detects a problem, an error code will be displayed. Anytime this happens, press self
test button to retest. If error code is still displayed and does not appear in this chart, have control module
checked or replaced.
Other problem situations and their possible causes and solutions are listed in the chart below.
Problem Possible cause Possible solution
No ESID connection after
drilling unit key has been on
at least one minute Problems in startup Push self test button. If problem goes
away, retest strike system
No power to strike system
control module Check drilling unit electric system
Check that harness from drilling unit
to control module is connected
Check that cable from drilling unit
carries more than 10V
Defective control module Have control module checked or
replaced
Defective CAN bus connection Ensure CAN cable from drilling unit to
ESID control module is connected
Strobe light on drilling unit
does not work during total
test Improper connections with
control module Check connections and wiring
harness
Defective strobe light 1. Disconnect strobe and connect to
external 12V power source.
2. If strobe does not work, replace it.
Defective control module Have control module checked or
replaced
Alarm on drilling unit does
not work during total test Improper connections with
control module Check connections and wiring
harness
Defective alarm 1. Disconnect strobe and connect to
external 12V power source.
2. If strobe does not work, replace it.
Defective control module Have control module checked or
replaced
Strobe light and alarm on
drilling unit do not work
during total test Improper connections with
control module Check connections and wiring
harness
Defective control module Have control module checked or
replaced
