Installation 17
2.9 CN4 Manual Pulsar
The signals on CN4 are for manual pulsar input.
Note: The +5V and GND pins are directly given by the PCI-bus
power. Therefore, these signals are not isolated.
No. Name Function (Axis)
1 VDD Isolated Power +5V
2 PA+ Pulser A+ phase signal input
3 PA- Pulser A-phase signal input
4 PB+ Pulser B+ phase signal input
5 PB- Pulser B-phase signal input
6 EXGND External Ground
7 N/A Not Available
8 N/A Not Available
9 N/A Not Available
Table 2-4: CN4 Manual Pulsar
