Function Library 181
erc_logic : Set the active logic for the ERC signal
erc_pulse_width : Set the pulse width of the ERC signal
erc_mode :
sd_logic :
sd_latch : Set the latch control for the SD signal
Value Mmeaning
0 Negative logic
1 Positive logic
Value Meaning
0 12
μ
s
1 102
μ
s
2 409
μ
s
3 1.6 ms
4 13 ms
5 52 ms
6 104 ms
7 Level output
Value Meaning
0 Disable
1 Output ERC when stopped by EL, ALM, or EMG input
2 Output ERC when complete home return
3 Both 1 and 2
Value Meaning
0 Negative logic
1 Positive logic
Value Meaning
0 Do not latch
1 latch
