8 Introduction
1.3 Supported Software
1.3.1 Programming Library
Windows 2000/XP/Vista DLLs are provided for the PCI-8154.
These function libraries are shipped with the board.
1.3.2 MotionCreatorPro
This Windows-based utility is used to setup cards, motors, and
systems. It can also aid in debugging hardware and software prob-
lems. It allows users to set I/O logic parameters to be loaded in
their own program. This product is also bundled with the card.
Refer to Chapter 5 for more details.
1.4 Available Terminal Board
ADLINK provides the servo & steppers use terminal board for
easy connection. For steppers, we provide DIN-100S which is pin-
to-pin terminal board. For servo users, ADLINK offers DIN-814M,
DIN-814M-J3A, DIN-814Y and DIN-814P-A4. The suitable servos
are listed as follows:
Mitsubishi J2 Super DIN-814M
Mitsubishi J3A DIN-814M-J3A
Yaskawa Sigma II DIN-814Y
Panasonic MINAS A4 DIN-814P-A4
