194 Function Library
B_8154_set_trigger_comparator(ByVal AxisNo As
Integer, ByVal CmpSrc As Integer, ByVal
CmpMethod As Integer, ByVal Data As Long) As
Integer
B_8154_set_latch_source(ByVal AxisNo As Integer,
ByVal LtcSrc As Integer) As Integer
B_8154_set_ltc_logic(ByVal AxisNo As Integer,
ByVal StcLogic As Integer) As Integer
B_8154_get_latch_data(ByVal AxisNo As Integer,
ByVal CounterNo As Integer, Pos As Double)
As Integer
@ Argument
AxisNo : Axis number designated to move or stop.
Logic : logic of comparing trigger
CmpSrc : The comparing source counters
card_id Physical axis AxisNo
0
0 0
1 1
2 2
3 3
1
0 4
1 5
… …
Value Meaning
0 Negative logic
1 Positive logic
Value Meaning
0 Command counter
1 Feedback counter
2 Error counter
3 General counter
