Controls and Features
Front Side / Top Surface / Right Side
m
[ U S E
[T] Control panel
For details, refer to “Control Panel” (page 9).
[2] Exhaust vents
Vents for cooling fans through which warm air comes out.
CAUTION
’ Do not block the exhaust vents, or heat builds up inside,
possibly causing a fire. Also, do not touch the vents, or this
could cause a low-temperature burn.
3] Carrying handle
Raise this handle when carrying the projector.
[4] Adjustable foot (for adjusting upper/lower angles)
It is adjusted to be level when shipped from the factory.
Turning to extend the foot allows adjustment up to + 7°.
CAUTIONS
’ When carrying the projector, do not give a shock to it. Be
careful to keep its balance.
• Do not carry it while the light source lamp is on or the cooling
fan is operating. This could cause personal injury.
Built-in speaker (ieft)
Built-in speaker (right)
¡T| Lens
Projection lens, which is an electrically driven, approx. 1.5
X zoom lens. Before projection, remove the lens cap.
[|] Lens cap
The cap has a string attached and the string is fixed to the
projector when shipped from the factory. It is recommended
that the cap be fitted on to prevent the lens becoming dirty
when the projector is not used.
Remote sensor
When operating with the remote control, aim it toward this
sensor. You can also operate the remote control by pointing
it to a screen and allowing the remote sensor to receive
the reflected light.
