Controls and Features (cont.)
Connector Panel (Cont.)
PC IN-2 terminal (BNC)
These are input terminals for analog RGB signals, vertical
sync (V) signals, and horizontal sync (H) signals /composite
signals (Cs). Devices which have analog RGB signal output
terminals can be connected.
To input the composite sync signals (Cs) to this unit, use
the horizontal sync (H) terminal.
* Input of external sync signals is automaticaliy
detected.
Detection of H/D signals or Cs signals causes automatic
switch to external sync. The priority order is H/D > Cs.
CAUTION
' When computer signals are input, the uppermost edge of
the screen may appear bowing if the sync signal input is
composite sync (Cs) or G on sync signal. In that case, use
separate sync signals for vertical sync (V) and horizontal sync
(H).
1^ “audio” input terminal (stereo mini jack)
This is an audio input terminal for PC IN 2 terminal. Connect
the audio output signal of a device connected to PC lN-2
terminal.
* When input to COMPUTER 2 is selected, the audio signal
input is reproduced by the projector’s speakers. Also,
signals can be output from the “audio OUT” terminal.
(However, if a cabie is connected to “audio OUT” terminal,
audio sound does not come out from the projector’s
speakers.)
PC IN-1 terminal (D-sub 3- row 15 pin)
This is an input terminal (PC) dedicated for computer
signals (RGB video signals and sync signals).
Connect the display output terminal of the computer to this
terminal. When a Macintosh computer is to be connected,
use the Conversion adapter for Mac supplied.
CAUTION
' When computer signals are input, the uppermost edge of
the screen may appear bowing if the sync signal input is
composite sync (Cs) or G on sync signal. In that case, use
separate sync signals for vertical sync (V) and horizontal sync
(H).
12 ] “audio” input terminal (stereo mini jack)
This is an audio input terminal for PC IN-1 terminal. Connect
the audio output signal of a device connected to PC IN-1
terminal.
* When input to COMPUTER 1 is selected, the audio signal
input is reproduced by the projector’s speakers. Also,
signals can be output from the “audio OUT” terminal.
(However, if a cable is connected to “audio OUT” terminal,
audio sound does not come out from the projector’s
speakers.)
