Specifications (Cont.)
Horizontal sync/composite sync signal (H/Cs)
H ; 1 to 5Vp-p, high impedance (positive/negative polarity)
Cs : 1 to 5Vp-p, high impedance (positive/negative polarity)
Vertical sync signal (V)
V : 1 to 5Vp-p, high impedance (positive/negative polarity)
* Some connected devices may not correspond to composite sync (Cs) or G on sync signal.
' “audio” for PC IN-2
[Computer output]
• “monitor”
1-line, stereo mini-jack x 1
O.SVrms, high impedance
1-line, D-sub 3-row 15-pin x 1
Analog RGB signal
R ; 0.7Vp-p, 75Q
B : 0.7VP-P, 75Q
G : 0.7Vp-p, 75Ì2
G on sync : 1 Vp-p, 75Q (negative sync)
Horizontal sync/composite sync signal (H/Cs)
H ; TTL level (Polarity : Same for input)
Cs : TTL level (Polarity : Same for input)
Vertical sync signal (V)
V : TTL level (Polarity : Same for input)
’ “audio OUT”
[Control]
• RS-232C
1-line, stereo mini-jack x 1
0 to O.SVrms (variable output)
: 1-line, D-sub 9-pin x 1
* RS-232C-interface specified control terminal for controlling this projector with a personal
computer.
• “remote”
[Other]
• Audio power output
(effective)
• Built-in speaker
G eneral
: 1-line, mini-jack X 1
* Remote terminal for connecting an infrared remote sensor extension unit, etc.
1 W-t-1 W
6 X 3 cm (2-Va'' x l-Ve") oval type x 2, impedance 8Q
• Power requirements
' Power consumption
> Allowable operation temperature
- Allowable relative humidity
• Allowable storage temperature
• Maximum outside dimensions
• Weight
' Accessories
AC 120 V, 60 Hz
8 A (7 W during stand-by)
-r 5°C to -t- 35°C (41 °F to 95°F)
20% to 80% (no condensation)
- 10°C to-r 60°C (14“Fto 140°F)
Approx. (W)425 X (H)246 x (D)375 mm (16-W x 9-%" x 14-78”)
(excluding protruding parts)
Approx. 32.56 lbs.(14.8kg)
(Refer to page 5.) *
* Design and specifications are subject to change without notice.
*D-iLA devices are manufactured with a very high-precision technology, allowing 99.99% of the pixels to be effective. Only
0.01% or less of the pixels are missing or always on.
* For easy understanding, pictures and illustrations are shown by being emphasized, omitted or composed, and may be more
or less different from actual products.
*TRADEMARKS
IBM, IBM PC, and VGA are registered trademarks of International Business Machines Corporation. Macintosh is registered
trademarks of Apple Computer, Inc.
VESA is a trademark of the non-profit organization Video Electronics Standard Association.
All other product names mentioned herein are used for identification purposes only, and may be the trademarks or registered
trademarks of their respective companies.
