Connecting to Various Devices
* Before connection, be sure to turn off the projector and connected devices.
* Read the manual which comes with each device thoroughly.
Signals that Can Be Input to the Projector
The following signals can be input to the projector:
■ Video signals
(1) Response to color systems
' -___Color system
Input terminal ~~
NTSC NTSC4.43 PAL SECAM
video О О 0 О
S-video о 0*1 О
video/y, c/cb(b-y), cr(r-y) 0*2 0*2 0*2 0*2
G, B, R, H,V 0*2 0*2 0*2 0*2
*1 ; Responds if “S-video” output is available.
* 2 : Signifies that component signals conform to the signal timing (synchronization and video period) of each color system. The
color systems are used for convenience only.
(2) Response to double density (*1), high-vision signals
Input terminal NTSC*2 PAL*3 High-vision signal
video/y, c/cb(b-y), cr(r-y) 0 О О
G, B, R, H, V 0 0
о
: Signals whose density of scanning lines/tield is twice as high.
;: Responds to signals whose horizontal scanning frequency is 31.5 kHz. NTSC can be made twice as dense by a line doubler
(separately available; recommended article). Also, possible to respond to fully-specified, decoded wide-clear-vision signals
and 525P progressive signals.
1 : Responds to signals whose horizontal scanning frequency is 33.5 kHz. PAL can be made twice as dense by a line doubler
(separately available: recommended article).
Computer signals
• Signals with the following resolutions can be input to the input terminal of PC IN-1 (analog RGB) or PC IN-2 (G, B, R, H, V).
(The following signals are preset.)
Screen resolution (standard name) Horizontal frequency Vertical frequency Scanning method
640x400 (PC-9801) 24.8kHz 56.4Hz Non-interlace
640 X 350 (VGA1) 31.5kHz 70.1Hz Non-interlace
640 X 480 (VGA3) 31.5kHz 59.9Hz Non-interlace
640 X 480 (Macintosh 13”) 35.0kHz 66.7Hz Non-interlace
640 X 480 (VGA VESA) 37.5kHz 75.0Hz Non-interlace
800x600 (SVGA1) 37.9kHz 60.3Hz Non-interlace
800 X 600 (SVGA2) 48.1kHz 72.2Hz Non-interlace
832 X 624 (Macintosh16”) 49.7kHz 74.6Hz Non-interlace
1024x768 (XGA1) 48.4kHz 60.0Hz Non-interlace
1024x768 (XGA2) 56.5kHz 70.1Hz Non-interlace
1024 X 768 (Macintosh 19”) 60.2kHz 74.9Hz Non-interlace
1152 X 870 (Macintosh 21”) 68.7kHz 75.0Hz Non-interlace
1280x1024 (SXGA1) 64.0kHz 60.0Hz Non-interlace5
1280x 1024 (SXGA2) 70.8kHz 67.0Hz Non-interlace
1360 X 1024 (SXGA3: Mac Board) 80.0kHz 75.1Hz Non-interlace
• Interlace signals are not handled.
• Some signals other than listed above can be displayed. But they require adjustment. Even some of the signals listed above may require
adjustment depending on the video board used.
• When a signal other than listed above is input, the screen could be partially erased or an unneeded fold-over screen could appear.
• Even signals in the frequency range that can be input may not be displayed normally depending on the type of the signal.
• Composite sync.(Cs) and G on sync, signals cannot handled depending on the devices connected.
19
