BTH S E R V I C E H A N D B O O K

C O M P O N E N T I N F O R M A T I O N

PRESSURE SWITCHES (CONTINUED)

PRESSURE SWITCHES

PART NUMBER / ACTIVATION PRESSURE^

Model

Series

Blocked Inlet

Normally Closed

Opens on a fall

Blower Prover

Normally Open

Closes on a rise

Low Gas Pressure

Normaily Open

Cioses on a rise

Biocked Outiet

Normaliy Ciosed

Opens on a rise

BTH 120

966

193293-000/-1.00”

193295-000/+0.45”

191149-001 /+5.00”

193294-000/+2.00”

967

193356-000/-2.00”

193295-000/+0.45”

191149-004/+9.00”

193357-000/+4.00”

970

193293-000/-1.00”

194706-000/+1.00”

191149-005/+5.20”

193294-000/+2.00”

971

193356-000/-2.00”

194706-000/+1.00”

191149-004/+9.00”

193357-000/+4.00”

973

193356-000/-2.00”

194706-000/+1.00”

191149-004/+9.00”

193357-000/+4.00”

BTH 150

960

N/A

192811-000/+4.20”

N/A

192810-000/+4.35”

962

192882-000/-0.75”

193221-000/+0.45”

N/A

192878-000/+2.53”

966

193363-000/-0.76”

193295-000/+0.45”

N/A

193362-000/+2.60”

967

193355-000/-1.80”

193295-000/+0.45”

N/A

193357-000/+4.00”

970

193363-000/-0.76”

194706-000/+1.00”

N/A

193362-000/+2.60”

971

193355-000/-1.80”

194706-000/+1.00”

N/A

193357-000/+4.00”

973

193355-000/-1.80”

194706-000/+1.00”

N/A

193357-000/+4.00”

BTH 199

960

N/A

192811-000/+4.20”

N/A

192810-000/+4.35”

962

192882-000/-0.75”

193221-000/+0.45”

N/A

192878-000/+2.53”

966

193363-000/-0.76”

193295-000/+0.45”

N/A

193364-000/+2.87”

967

193356-000/-2.00”

193295-000/+0.45”

N/A

193357-000/+4.00”

970

193363-000/-0.76”

194706-000/+1.00”

N/A

193364-000/+2.87”

971

193356-000/-2.00”

194706-000/+1.00”

N/A

193357-000/+4.00”

973

193356-000/-2.00”

194706-000/+1.00”

N/A

193357-000/+4.00”

BTH 250

962

192947-000/-0.77”

193221-000/+0.45”

193222-000/+4.75”

192946-000/+4.16”

966

193361-000/-0.77”

193295-000/+0.45”

191149-001 /+5.00”

193357-000/+4.00”

970

193361-000/-0.77”

194706-000/+1.00”

191149-005/+5.20”

193357-000/+4.00”

t- Pressure values are given in inches of water column pressure (“W.C.).

Negative pressure values in this table are preceded by a minus sign and indicate pressure below

atmospheric: in a vacuum. Positive pressures are preceded by a “+” plus sign and indicate pressure above
atmospheric.

Technical Training Department
TC-044 Revision 6

36

A. O. Smith Water Products Co.

Ashiand City, Tennessee © 2004
