BTH S E R V I C E H A N D B O O K

T R O U B L E S H O O T I N G

ECO CHECK

STEP 4

24 VAC TO ECO

24 V

m

Black Black

Redj I j |Red

1

2

3

I ^'12

7^CN8

◄-----

1

2

Ground

_ t.

r

T y

^Temperature/

Eco Probe (Upper)

^Temperature

Probe #2 (Lower)

-Igniter

■CN5 -

I

1 I 'i A

STEP 4: CHECK FOR 24 VAC BETWEEN PIN 4 ON CONTROL BOARD TERMINAL CN3 AND
GROUND.

Condition:

• Disconnect CN3 plug from control board.

• On/Off switch is on.

Check for 24 VAC between pin 4 of the CN3 terminal on the control board and ground.

IF...

THEN

24 VAC is not present

replace the control board if Steps 1, 2, and 3 have been performed and the results

were successful.

24 VAC is present

continue to Step 5.

A. O. Smith Water Products Co.
Ashland City, Tennessee © 2004

21

Technical Training Department

TC-044 Revision 6
