06D,07D
INSTALLATION
Carrier
CONTENTS
Inspect the Site
PAGE
13
Inspect Shipment for Loss and Damage
15
Set the Unit in Place
15
Code Compliance
15
Electrical Requirements
15
Piping and Accessories
20
Leak Test the System
24
Dehydrate the System
24
Check Refrigerant Charge
26
Initial Start-Up Instructions
27
Checking Operations
27
07DA210,112,215 Electrically Operated Capacity
Control Device
28
Check the Installation
32
SUCTION
SHUT-OFF VALVE
DISCHARGE MANIFOLD
PRE5SURESTAT CONN.
PUMP END BEARING
HEAD
OIL PUMP COVER
SUCTION MANIFOLD
PRESSURESTAT CONNECTION
(REMOVE FITTING TO
CHECK OIL LEVEL WITH
DIPSTICK)
COMPRESSOR NAMEPLATE
REGISTER TAG
FUSIBLE UNION
COOLING WATER
CONN
WATER REGULATOR VALVE
PRESSURE CONNECTION
LIQUID LINE CONNECTION
liquid
line
valve
TERMINAL BLOCK
discharge
‘
shut
-
off
valve
DISCHARGE GAGE CONNECTION
RUN CAPACITOR
CONTROL BOX
DISCHARGE MUFFLER
CONDENSING UNIT
NAMEPLATE (USE
FOR WARRANTY
PURPOSES)
MOUNTING SPRINGS
(REMOVE BOLTS BEFORE STARTING)
CONDENSER NAMEPLATE
LIQUID LEVEL TEST
COCK
Fig. 1 - Typical 2 Cylinder Water-Cooled Condensing Unit
(07DA102, Single-Phase Illustrated)
