NOTES
1. NET WEIGHT INCLUDES OIL BUT NOT REFRIG. CHARGE.
2. OIL PUMP IS AUTOMATICALLY REVERSIBLE FOR
EITHER DIRECTION OF ROTATION.
3. CONTROL BOX DRAWING OSD-201-El
4. MUFFLER DRAWING OSD-202-4
PRESS. ACTUATED
CONTROL VALVE(S)
CONTROL BOX
MOUNTING SPRINGS
MUFFLER
CRANKCASE HEATER
YES
NO
MODE L
NET
WEIGHT
OIL
CHARGE
*
06D( )337
285 LBS.
10 PINTS
06 D( Ì537
SPRING MOUNTING ARRANGEMENT
( T Y P I C A L )
„ 06DA DENOTES NO UNLOADERS
06DE DENOTES 2 STEP PRESSURE
ACTUATED UNLOADING
ELECTRICAL
D
"E" CONNECTION SIZES
208-3-60
230-3-60
8"
1 3/8" DIA. HOLE FOR 1" CONN, a
1 3/4" DIA. K.O. FOR 1 1/4" CONN.
230-3-50
400-3-50
460-3- 60
9"
1 1/8" DIA. HOLE FOR 3-4" CONN.,
13/8" DIA K.O. FOR l" CONN. 8
1 3/4" DIA K.O. FOR 1 1/4" CONN.
Dimensions are approximate. Certified dimension drawings are available on request.
Fig. 12 - Dimensions for 06DA337,06DE337 and 06DA537,06DE537
