— 92 —
fn = 3: Function 3 Setting Memory Switch Value
GS (E pL pH fn [a1 b18 ··· b11] ··· [ak bk8 ··· bk1] fn = 3
[Code] <1d>H<28>H<45>pL pH fn[a1 b18···b11]···[ak bk8···bk1]
[Range] 10 (pL + pH
× 256) 65535
fn = 3
a = 1, 2, 3, 4
b = 48, 49, 50
[Outline] • Changes the memory switch set in a to the value set in “b”.
• Setting memory with 1 (a = 1)
b Function
48 Sets corresponding bit to OFF.
49 Sets corresponding bit to ON.
50 Does not change corresponding bit.
(Note) Differs with the number of columns (as much as font A full columns).
n b (Set Value) Function
1
48 (Default) Reports the power on.
49 Does not report power on.
2
48 (Default) Sets input buffer capacity to 4K bytes.
49 Sets input buffer capacity to 48 bytes. (Note)
3
48 (Default) Sets input buffer full and offline to be Busy.
49 Sets to be busy with input buffer full.
48 (Default) At the occurrence of receiving error, replaces the data
4
with “?”.
49 At the occurrence of receiving error, ignores the data.
5
48 (Default) Disables CR (0DH).
49 Enables CR (0DH).
6 48 (Default) Reserved
7
48 (Default) Does not reset at serial I/F pin 6.
49 Resets at serial I/F pin 6.
8
48 (Default) Does not reset at serial I/F pin 25.
49 Resets sat serial I/F pin 25.
