— 104 —
fn = 9: Function 9 Defining Data in the Raster Format to the Character
Code Page of Work Area
GS (E pL pH fn x c1 c2[y d1...d(y
× x)]k fn = 9
[Code] <1d>H<28>H<45>pL pH fn x c1 c2 [y d1...d(yXx)]k
[Range] 5 (pL + pH × 256) 65535
fn = 9
y = 1 (At selection of font C)
y = 2 (At selection of other than font C)
128 c1 c2 255
0 y 24 (At selection of font A)
0 x 17 (At selection of font B)
0 x 16 (At selection of font C)
0 d 255
k = c2 – c1 + 1
[Outline] Defines the data in raster format in units of character on the character code page in
work area.
Operates only in printer function setting mode.
Data structure (12
× 24)
d1 (odd number) d2 (even number)
Bits 6 through 0 are
not character data
