— 119 —
DLE DC4 fn d1...d7 (Specification of fn = 8)
[Function] Buffer clear
[Code] <10>H<14>H ...
[Range] fn = 8, d1 = 1, d2 = 3, d3 = 20, d4 = 1, d5 = 6, d6 = 2, d7 = 8
[Outline] • Erases all data in receiving buffer or print buffer.
• Sends the following 3-byte data group.
Hex. Decimal No. of Data
Header 37H 55 1 byte
Identifier 25H 37 1 byte
NULL 00H 0 1 byte
• Enters the state of selecting STANDARD MODE.
[Caution] • When receiving a code row coinciding with the code configuring this command,
the same operation as this command takes place and attention by the user is
required.
Example: When corresponding code row is present in bit image data.
• This command must not be used between other command code rows.
Example: This command is used in bit image data.
• This command is ignored during transmission of block data.
[See Also] ESC p
