— 10 —
ESC FF
[Function] Printing data in PAGE MODE
[Code] <1B>H<0C>H
[Outline] Executes a batch printout of the data mapped in the entire print area in PAGE MODE.
[Caution] • This command is only effective when PAGE MODE is selected.
• Mapped data, as well as the ESC T and ESC W settings, and the character mapping
position are held even after printing.
[See Also] Appendix 4.1 “Explanation on PAGE MODE”
FF, ESC L, ESC S
ESC J n
[Function] Printing and feeding paper in minimum pitch
[Code] <1B>H<4A>H
[Range] 0 n 255
[Outline] Prints the data held in the print buffer and feeds paper by [n
× basic calculation pitch]
inches.
[Caution] • After this command is executed, the beginning of the line is taken as the start position
for the next print.
• The line feed width can be set separately for the STANDARD and PAGE MODES.
• This command does not affect the line feed width defined by ESC 2 or ESC 3.
• The basic calculation pitch is set by GS P.
• Fractions resulting from calculation are corrected with the minimum pitch of the
mechanism, and the remainder is omitted.
• In STANDARD MODE, this command uses the vertical (paper feed direction) basic
calculation pitch (y).
• In PAGE MODE, this command acts differently depending on the start point:
(1) If the start point specified by ESC T is top left or bottom right, the command
uses the vertical (Paper feed direction) basic calculation pitch (y).
(2) If the start point specified by ESC T is top right or bottom left, the command
uses the horizontal (Perpendicular to the paper feed direction) basic calculation
pitch (x).
The maximum settable line feed width is 1016 mm (40 inches). A setting greater
than this maximum is trimmed to the maximum.
[Default] The initial value is not defined.
[Sample Program] Refer to Sample Program and Print Results for ESC 2.
