Esc p m n1 n2 – CITIZEN CT-S300 User Manual
Page 129
— 124 —
ESC p m n1 n2
[Function]
Generating the specified pulses
[Code]
<1B>H<70>H
[Range]
m = 0, 1, 48, 49
0 < n1 n2 255
[Outline]
• The signals specified by “n1” and “n2” are output to the connector pin specified by
“m”.
• “m” has the followings.
• The ON time is n1
× 2 ms, and OFF time n2 × 2 ms.
[Caution]
• When “m” is beyond a definition range, no signal is output, discarding “n1” and
“n2”.
• The drawer drive duty must be within the following range:
ON time
0.2
ON time + OFF time
(The OFF time should be 4 times or more longer than the ON time.)
[Sample Program]
LPRINT CHR$(&H1B) + "p"
LPRINT CHR$(0);
← Selects pin No. 2.
LPRINT CHR$(5);
← Sets ON time to 10 ms
LPRINT CHR$(50);
← Sets OFF time to 100 ms
m
Connector Pin
0, 48
Drawer kick-out pin No. 2
1, 49
Drawer kick-out pin No. 5
