— 98 —
fn = 6: Function 6 Sending the Set Customized Value
GS (E pL pH fn a fn = 6
[Code] <1d>H<28>H<45>pL pH fn a
[Range] (pL + pH
× 256) = 2 : (pL = 2, pH = 0)
fn = 6
1 a 3, a = 5, 6, 97, 116, 201, 202
[Outline] • Sends the set value of customized value set by “a”.
Hex. No. of Data
Header 37H 1
ID 27H 1
Customized value No. 30H ~ 39H 1 ~ 3
Separation number 1FH 1
Customized value 30H ~ 39H 1 ~ 5
NULL 00H 1
a
Sending Data
1st Byte 2nd Byte 3rd Byte
3 51 (“3”) — —
5 53 (“5”) — —
6 54 (“6”) — —
97 57 (“9”) 55 (“7”) —
116 49 (“1”) 49 (“1”) 54 (“6”)
201 50 (“2”) 48 (“0”) 49 (“1”)
202 50 (“2”) 48 (“0”) 50 (“2”)
• Configuration of customized value No.
• a = 3: When paper width is specified
* No function with CT-S300
Setting Status Sending Data
Stored Power
1st Byte 2nd Byte 3rd Byte 4th Byte 5th Byte
Value Width
1 58 mm 49 (“1”) — — — —
2* 60 mm 50 (“2”) — — — —
3 80 mm 51 (“3”) — — — —
