Form O-MAPS II, P/N 209179 R7, Page 20
9.0 Gas Heat
Section
Maintenance -
Models RDCA
and RDDA
This gas heater will operate with a minimum of maintenance. To ensure long
life and satisfactory performance, a heater that is operated under normal con-
ditions should be inspected and cleaned at the start of each heating season.
If the heater is operating in an area where an unusual amount of dust or soot
or other impurities are present in the air, more frequent maintenance is recom-
mended.
When any service is completed, be careful to reassemble correctly to ensure
that no unsafe conditions are created. When re-lighting, always follow the light-
ing instructions on the furnace.
8.0 Thermal
Expansion
Valves
NOTE: Thermostatic expansion valves for RDCA and
RECA are the same as for Model RCA. Thermostaticl
expansion valves for RDDA and REDA are the same
as for Model RDA.
IMPORTANT: Thermostatic expansion valve P/N's listed here are for use
with R22 refrigerant only. If the system is charged with R407C refrigerant
(check the rating plate), contact your distributor or the factory service depart-
ment for replacement information.
Checklist,
Steps 1-13 (cont'd)
If the acid test in Step 2 did not indicate a compressor burnout, remove the
temporary suction line filter drier.
CAUTION: Before returning to normal operation, remove the
temporary suction line filter drier. See Hazard Levels, pg 3.
 Step 13. Review Steps 1 through 12 to ensure that nothing was
overlooked.
 Step 12. (cont'd)
Model
Thermostatic Expansion Valves
(R22 Refrigerant)
Connection
Sizes
Inlet/Outlet
RCA RDA Compressor
- Ckt
P/N
Sporlan
Model
025 -- ZR22 - CKT A 204800 BBIVE-2-GA 1/2 / 5/8
037 -- ZR36 - CKT A 204799 BBIVE-3-GA 1/2 / 5/8
059 --
ZR36 - CKT A 204799 BBIVE-3-GA I/2 / 5/8
ZR22 - CKT B 204800 BBIVE-2-GA 1/2 / 5/8
060 --
ZR36 - CKTA 204799 BBIVE-3-GA 1/2 / 5/8
ZR22 - CKT B 204800 BBIVE-2-GA 1/2 / 5/8
077 --
ZR54 - CKT A 204801 BBIVE-5-GA 1/2 / 7/8
ZR22 - CKT B 204800 BBIVE-2-GA 1/2 / 5/8
078 102
ZR54 - CKTA 204801 BBIVE-5-GA 1/2 / 7/8
ZR22 - CKTB 204800 BBIVE-2-GA 1/2 / 5/8
090 114
ZR54 - CKT A 204801 BBIVE-5-GA 1/2 / 7/8
ZR36 - CKT B 204799 BBIVE-3-GA 1/2 / 5/8
108 126
ZR72 - CKT A 178509 BBIVE-6-GA 1/2 / 7/8
ZR36 - CKT B 204799 BBIVE-3-GA 1/2 / 5/8
109 --
ZR72 - CKT A 178509 BBIVE-5-GA 1/2 / 7/8
ZR36 - CKT B 204799 BBIVE-3-GA 1/2 / 5/8
120 144
ZR72 - CKT A 178509 BBIVE-6-GA 1/2 / 7/8
ZR54 - CKT B 204801 BBIVE-5-GA 1/2 / 7/8
139 --
ZR54 - CKT A 204801 BBIVE-3-GA 1/2 / 5/8
ZR54 - CKT B 204801 BBIVE-5-GA 1/2 / 7/8
ZR36 - CKT D 204799 BBIVE-3-GA 1/2 / 5/8
164 --
ZR36 - CKT D 177381 BBIVE-3-GA 1/2 / 1/2
ZR54 - CKT B 204801 BBIVE-5-GA 1/2 / 7/8
ZR72 - CKT A 178509 BBIVE-6-GA 1/2 / 7/8
166 188
ZR36 - CKT C 204799 BBIVE-3-GA 1/2 / 5/8
ZR54 - CKT A 204801 BBIVE-5-GA 1/2 / 7/8
ZR72 - CKT B 178509 BBIVE-6-GA 1/2 / 7/8
Model
Thermostatic Expansion Valves
(R22 Refrigerant)
Connection
Sizes
Inlet/Outlet
RCA RDA Compressor - Ckt P/N Sporlan Model
184 220
ZR54 - CKT C 204801 BBIVE-5-GA 1/2 / 7/8
ZR54 - CKT A 204801 BBIVE-5-GA 1/2 / 7/8
ZR72 - CKT B 178509 BBIVE-6-GA 1/2 / 7/8
198 234
ZR72 - CKT C 178509 BBIVE-6-GA 1/2 / 7/8
ZR54 - CKT A 204801 BBIVE-5-GA 1/2 / 7/8
ZR72 - CKT B 178509 BBIVE-6-GA 1/2 / 7/8
176 230
ZR72 - CKT A 204801 BBIVE-5-GA 1/2 / 7/8
ZR72 - CKT B 207801 EBSVE-11-GA 5/8 / 1-1/8
226 280
ZR72 - CKT C 178509 BBIVE-6-GA 1/2 / 7/8
ZRT144 - CKT A&B 207801 EBSVE-11-GA 5/8 / 1-1/8
292 346
ZR72 - CKT C 207801 EBSVE-11-GA 5/8 / 1-1/8
ZRT144 - CKT A&B 207801 EBSVE-11-GA 5/8 / 1-1/8
374
428
ZR125 - CKT C 207801 EBSVE-11-GA 5/8 / 1-1/8
ZR125 - CKT A 207801 EBSVE-11-GA 5/8 / 1-1/8
ZR125 - CKT B 207801 EBSVE-11-GA 5/8 / 1-1/8
446
ZR125 - CKT C 207801 EBSVE-11-GA 5/8 / 1-1/8
ZR125 - CKT A 207801 EBSVE-11-GA 5/8 / 1-1/8
ZR125 - CKT B 207801 EBSVE-11-GA 5/8 / 1-1/8
Re-Heat
Pump -
Model RDA
Thermostatic Expansion Valves
(R22 Refrigerant)
Connection
Sizes
Inlet/Outlet Compressor - Ckt P/N Sporlan Model
102 ZR22 - CKT Dh 177381 BBIVE-3-GA 1/2 / 1/2
114 ZR22 - CKT Dh 177381 BBIVE-3-GA 1/2 / 1/2
126 ZR22 - CKT Dh 177381 BBIVE-3-GA 1/2 / 1/2
144 ZR22 - CKT Dh 177381 BBIVE-3-GA 1/2 / 1/2
188 ZR22 - CKT Dh 177381 BBIVE-3-GA 1/2 / 1/2
220 ZR36 - CKT Dh 179306 BBIVE-5-GA 1/2 / 1/2
230 ZR36 - CKT Dh 178509 BBIVE-6-GA
234 ZR36 - CKT Dh 179306 BBIVE-5-GA 1/2 / 1/2
280 ZR36 - CKT Dh 179306 BBIVE-5-GA 1/2 / 1/2
346 ZR36 - CKT Dh 178509 BBIVE-6-GA
428 ZR36 - CKT Dh 178509 BBIVE-6-GA
446 ZR36 - CKT Dh 194153 BBIVE-8-GA
7.0 Compressor
Maintenance
and
Replacement
(cont'd)
