Reznor MAPSII Series REDA Users Manual User Manual
Maps, Ii model rdca, Operation/maintenance/service warning

Form RZ-NA O-MAPS II, P/N 209179 R7, Page 1
�
FORM O-MAPS II (Version B)
Obsoletes Form O-MAPS II (Version A)
Applies to:
MAPS II Model Series RCA, RDA,
RDCA, RDDA, RECA, and REDA
Modular Air Processing Systems
MAPS
®
II Model RDCA
���
��
��������
��
����� �����
�
��
����
�
��
��
��
�
�
�
��
�
�
�
�
��
�
��
�
�
���
��
��
�
����
��
�
Operation/Maintenance/Service
WARNING:
All systems contain chlorodifluoromethane (HCFC-22) or a hydro-fluorocarbon
blend (HFC-407C). HCFC-22 is believed to harm the public health and environment
by destroying ozone in the upper atmosphere. Do not release HCFC-22 to
the atmosphere. The U.S. Clean Air Act requires the recovery of any residual
refrigerant.
IMPORTANT: Do not release refrigerant to the atmosphere! If required service
procedures include the adding or removing of refrigerant, the service technician
must comply with all federal, state and local laws. The procedures discussed in
this manual should only be performed by a qualified HVAC technician.
WARNING:
Improper installation, adjustment, alteration, service, or maintenance can cause
property damage, injury, or death. Read the installation, operation, and maintenance
®
®
™
Document Outline
- 1.0 GENERAL
- 2.0 Maintenance Requirements
- Maintenance Schedule
- Cross-Reference by Model/Size and Cabinet Size A, B, or C
- 3.0 Filters
- 4.0 Belt
- 5.0 Coil Maintenance
- 6.0 Check Refrigerant Pressure and Temperatures
- Check Refrigerant Pressure
- Check Refrigrant Temperatures
- 7.0 Compressor Maintenance and Replacement
- Handling
- Compressor Maintenance Checklist, Steps 1-13
- 8.0 Thermal Expansion Valves
- 9.0 Gas Heat Section Maintenance - Models RDCA and RDDA
- Burner Maintenance
- Venter Motor and Wheel
- Gas Valves
- Combustion Air Pressure Switch
- Limit Control
- 10.0 Electric Heat Section Maintenance - Models REDA and RECA
- 11.0 Troubleshooting
- General Refrigeration Circuit
- Troubleshooting Gas Heat Section - Models RDCA and RDDA
- Troubleshooting the Electric Heat Section - Models REDA and RECA
- Index
