DSMC MODULES
This section provides the technical specifications for DSMC modules.
DSMC SIDE HANDLE
SPECIFICATION DESCRIPTION
Dimensions Height: 4.96 in. (126 mm)
Width: 2.76 in. (70 mm)
Depth: 3.31 in. (84 mm)
Weight Approximately 1.01 lbs (458 g), Module only
Construction Aluminum Alloy
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature –30°C to 70°C (–22°F to 158°F)
MODULE ADAPTOR
SPECIFICATION DESCRIPTION
Dimensions Height: 4.29 in. (109 mm)
Width: 3.54 in. (90 mm)
Depth: 0.87 in. (22 mm)
Weight Approximately 0.61 lbs (278 g), Module only
Construction Aluminum Alloy
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature –30°C to 70°C (–22°F to 158°F)
