REMOVE A DSMC POWER MODULE
REQUIRED TOOL: T20 Torx driver
1. Turn off the BRAIN.
2. Use a T20 Torx driver to rotate the lock on the adaptor module counterclockwise to the Unlock position.
3. Rotate the module upwards and away from the adaptor module to disengage.
4. Remove the module.
