RED DSMC POWER OPERATION GUIDE

955-0038, REV-F

RED BRICK CHARGER LED INDICATORS

COLOR PATTERN

DESCRIPTION

Green

Charger on, battery fully charged

Red/Green flashing (alternating)

Charger on, fail condition

Red

Charger on, no battery connected

Amber flashing

Charger on, battery connected and charging

RECHARGE RED BRICKS

1. Connect the RED BRICK Charger to a 100–240 VAC, 50/60 Hz power outlet.
2. Turn on the RED BRICK Charger using the power switch.
3. Align and lower the RED BRICK into the V-plate adaptor.
4. Charge the battery until the LED indicator turns green, signalling a fully charged battery.
5. Press the release tab and remove the RED BRICK by pulling it up and off of the RED BRICK Charger.
NOTE: When a 6-pin LEMO is connected to the auxiliary power output, the charging process is suspended. The

auxiliary LED illuminates and the battery LEDs on the charger flashes green. Once the cable is unplugged, the

RED BRICK Charger resumes charging.
