RED BRICK CHARGER

The RED BRICK Charger offers rechargeable support for RED BRICK (153 Wh) lithium-ion batteries. The RED

BRICK Charger provides up to 4 A in constant current mode. The RED BRICK Charger charges two (2) at-

tached RED BRICK batteries sequentially in approximately six (6) to eight (8) hours. The RED BRICK Charger

can charge one (1) fully discharged RED BRICK in approximately three (3) hours.
The RED BRICK Charger also serves as a power supply using the 6-pin LEMO auxiliary output port.
WARNING: DO NOT exceed 100 W power draw from the 6-pin LEMO auxiliary output port.
NOTE: The RED BRICK Charger stops charging automatically if battery temperature exceeds 40˚C (104˚F), or

drops below 0°C (32°F).

PREPARE THE RED BRICK CHARGER

When the RED BRICK Charger is brand new, it may be difficult to connect and disconnect the V-plate adaptor

on the RED BRICK. RED recommends that you perform a break-in sequence with a new RED BRICK Charger.

Before charging a RED BRICK in the charger, fully engage and then disengage the RED BRICK approximately

20 times.

RED BRICK Charger
