6 PRG SERIES 400 ® POWER AND DATA DISTRIBUTION SYSTEM USER MANUAL
Several types of data distribution devices are available for expansion of the Series 400 System.
Ethernet Switches
The Series 400 Ethernet Switches provide a powerful and convenient interface between Virtuoso® or DMX512 control
consoles and their control equipment. For complete installation and operation instructions, refer to the following
manual:
+ Series 400 Ethernet Switch User Manual (02.9801.0001).
Nodes
The Virtuoso® Node units provide a powerful and convenient interface between Virtuoso or Art-Net compatible
control consoles, pixel mapping from media servers, and subsequent control equipment which require either Art-Net
(Virtuoso Node Plus only) or DMX512 control signals (Virtuoso Node Plus and Virtuoso Node). For complete
installation and operation instructions, refer to the following manuals:
+ Virtuoso® Node Plus User Manual (02.9801.0301)
+ Virtuoso® Node User Manual (02.9669.0001)
Figure 1-3: Switches and Nodes
10-Port Fiber Optic
Ethernet Switch
Ethernet Switches
Nodes
20.9801.0201
7-Port Copper
Ethernet Switch
20.9801.0201.07
Virtuoso Node Plus
20.9801.0300
Virtuoso Node
20.9669.0030
2.38380-42 2.38380-46
2.37999- 2.37997-
Virtuoso Node 2
20.9801.1000
2.37998-
