Potter PFC-6075 User Manual
Page 115
6-109
PFC-6075 • 5403593 • Rev C • 2/13
Notes:
If a power supply is Class A, select the applicable NACs (NAC 1/2, NAC 3/4 or NAC 5/6).
y
If a power supply is Class B, programming is completed.
y
Class-A operation may be independently selected for the P-Link repeater output and any of the NAC circuit pairs.
y
Repeat steps, as needed, to continue creating or adding additional power supplies.
4.
Deleting a Power Supply
To delete a power supply:
Select the
1.
Power Supply function from the system panel to display all current power supplies.
Example of Power Supply Window
Figure 152.
Note: The Internal Power Supply may not be deleted as indicated by the message in the following dialog box.
Example of Dialog Box - Showing Internal Power Supply Cannot Be Deleted
Figure 153.
Click anywhere in the power supply's line item, then click the
2.
"Delete Device" button.
Tip: You may delete more than one power supply in one step by first selecting a range or group using Window's SHIFT
CLICK or CTRL CLICK methods, respectively.
Click anywhere in power
supply's line to select it.
