64
PRINTED IN USA PAGE 1 OF 2 MFG #5401250 - REV A
12/09
PFC-4410RC
RELEASING CONTROL PANEL
Potter Electric Signal Co., LLC • St. Louis, MO • Cust Service: 866-240-1870 • Tech Support:866-956-1211• Canada 888-882-1833 • www.pottersignal.com
• Multi-Hazard Operation
• Four Class B Initiating Circuits
• Two Class B Supervisory Circuits **
• Four Class B Output Circuits
• Programmable Cross Zoning
• Supervised Microprocessor
• 32 Character Alpha-Numeric LCD Display
• Custom Banner Message and Zone Description text
• Custom Zone Description Text
• On Board Menu Driven Programming Controls
• Releasing Circuits Protected From False Activation
• Continuous or Timed Discharge
• 40 Event History Buffer
• Walktest with Automatic Time-out
• Alarm, Trouble Supervisory, and Waterflow relays
• Optional Class A Initiating Zone and output module
• 34 character LED supplemental display
• 19 Standard Programs in Panel Memory
• Password Protection for all Programming
• 24 Hour Clock
• Suitable for agent or water-based extinguishing
• Programmable pre-discharge timers*
• One Class B Abort circuit* (Defaults to additional supervisory zone
in water based mode.)
• Three Abort modes*
* Available in Chemical mode only
** One zone programmable as abort in chemical mode.
Ordering Information
Model Number
Description Stock Number
PFC-4410RC 4 Zone Releasing Control (White Cabinet) 3006144
PFC-4410RC 4 Zone Releasing Control (Red Cabinet) 3006142
PFC-TW Bezel for Semi-Flush Mounting (White) 5090157
PFC-TR Bezel for Semi-Flush Mounting (Red) 5090155
BT-40 Battery, 12V 4AH for 24 hour standby (2 Req’d) 5130092
BT-80 Battery, 12V 8AH for 60 hour standby (2 Req’d) 5130084
BT-120 Battery, 12V 12AH for 90 hour standby (2 Req’d) 5130090
BT-180 Battery, 12V, 18AH for 90 hour standby (2 Req'd) 5130086
CA2Z 2 Zone Class A Initiating Circuit Module 3006013
CAM Class A Indicating Circuit Module 3005300
ARM-44 Relay Module for PFC-4410RC 3006221
ARM-2 Auxiliary Relay Module 3004725
RA-4410RC Remote Annunciator 3006400
BB-RA-44R Surface Mount Back Box for RA-4410RC (Red) 3006401
Dimensions: 18 ¼" x 14 ½" x 4 ¾"
General Description
The Potter Model PFC-4410RC is a flexible multi-hazard releasing control
panel that is well suited for a number of applications. The PFC-4410RC is
listed for use with pre-action and deluge sprinkler suppression systems and
agent based fire suppression systems.
The panel utilizes a microprocessor-based system that has 19 Standard
Programs, which covers a majority of installations. The simple to follow Menu
Structure programs the entire system in a matter of minutes. In addition to the
Standard Programs, the panel allows custom programming to accommodate
any installation.
The panel is Ninth Edition UL listed, ULC listed, Factory Mutual, California
State Fire Marshal (CSFM) and New York Materials Equipment Acceptance
(MEA) approved.
The PFC-4410RC is housed in a durable steel cabinet with removable door
and key lock. The panel is available in either a red or white finish and an
optional flush mount trim ring is available. The cabinet contains knockouts
on the side, back and top of the cabinet to ease installation. In addition, the
cabinet will house up to 18 amp-hour batteries that will provide in excess of
90 hours of standby power.
UL and ULC Listed, FM Approved, NYMEA Accepted, and CSFM
Approved
