4-26 Installing Hardware Options
Writer: Tom Erber Project: ProLiant 3000 Setup and Installation Guide Comments: 296908-002
File Name: E-CH04.DOC Last Saved On: 1/27/98 4:20 PM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
SCSI Channel A or Channel B
3 6
1 5
0 4
Figure 4-24. SCSI ID Numbers - Single SCSI Channel (Simplex Mode) with 1.6-inch drives
SCSI Channel A SCSI Channel B
3 3
2 2
1 1
0 0
Figure 4-25. SCSI ID Numbers - Dual SCSI Channels (Duplex Mode) with 1-inch drives
SCSI Channel A SCSI Channel B
3 3
1 1
0 0
Figure 4-26. SCSI ID Numbers - Dual SCSI Channels (Duplex Mode) with 1.6-inch drives
