Compaq PROLIANT 3000 User Manual
Page 71
4-10
Installing Hardware Options
Writer: Tom Erber Project: ProLiant 3000 Setup and Installation Guide Comments: 296908-002
File Name: E-CH04.DOC Last Saved On: 1/27/98 4:20 PM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
J1
J2
J3
J4
Bank 1
Bank 2
Figure 4-8. Memory banks on the system board
J12
J11
J10
J9
J8
J7
J6
J5
Note: Both sockets in a memory bank must be populated.
Bank 6
Bank 5
Bank 4
Bank 3
Figure 4-9. Memory banks on the memory board
