1. Pull the slide rails forward from the mounting brackets.
2. Carefully align the server's component rails with the rack's slide rails
and slide the server into the rack.
CAUTION: Be sure to keep the component parallel to the floor
when sliding the component rails into the slide rails. Tilting the
component up or down could result in damage to the rails.
Figure 3-14. Loading the rack server
