Compaq PROLIANT 3000 User Manual
Page 85
4-24
Installing Hardware Options
Writer: Tom Erber Project: ProLiant 3000 Setup and Installation Guide Comments: 296908-002
File Name: E-CH04.DOC Last Saved On: 1/27/98 4:20 PM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
2
1
Figure 4-22. Installing a SCSI drive
IMPORTANT: If the drive cage is configured for simplex mode (Pass-
Thru board installed) and you are using 1-inch drives, do not use drive bay
7 (see Figure 4-25). If you install a drive in bay 7, the service LED for that
drive will light and the drive will be inaccessible.
