1-10 Compaq ProLiant 3000 Server Features
Writer: Tom Erber Project: ProLiant 3000 Setup and Installation Guide Comments: 296908-002
File Name: B-CH01.DOC Last Saved On: 1/27/98 4:09 PM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
■ Ease of Use - The Integrated Management Display provides a 16x4
character display and four button control panel to easily navigate
through menus.
For information about using the IMD, see Chapter 6, “Advanced Feature
Operation.”
Supported Drive Configurations
Standard server configurations can include as many as seven SMART-2 or
SMART-2SL Controllers, depending on the installed network operating system.
The SMART-2 controller can support two Compaq ProLiant Storage Systems
or one Compaq ProLiant Storage System and up to eight internal, hot-pluggable
hard drives. The SMART-2SL controller can support one Compaq ProLiant
Storage System or seven internal, hot-pluggable hard drives.
A maximum practical SCSI configuration, optimizing performance and storage,
could include the following:
■ One network interface controller (NIC)
■ Seven SMART-2 or SMART-2SL Controllers
■ Twelve Compaq ProLiant Storage Systems
■ Ninety 9.1 GB drives
This configuration would yield a total storage capacity of 819 gigabytes.
