4-7
ProLiant 3000 Setup and Installation Guide
Writer: Tom Erber Project: ProLiant 3000 Setup and Installation Guide Comments: 296908-002
File Name: E-CH04.DOC Last Saved On: 1/27/98 4:20 PM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
System Board Switches
The following table defines the six switches on the system board. The Open
(OFF) position is the default configuration for each switch.
Table 4-1
System Board Switches
Switch Open (Off) Position Closed (On) Position
1 Video Enable integrated video Disable integrated video
2 Lock
Configuration Configuration can be
changed Configuration can not be
changed
3 Rack Mount System is tower configuration System is rack mount
configuration
4 Diskette
Override Diskette boot is controlled by
configuration Diskette is enabled for booting
regardless of configuration
5 Password
Enable Power on password is
enabled Power on password is disabled
6 Maintenance* NV RAM is valid NV RAM is invalidated,
configuration is lost
* See the ProLiant 3000 Service and Maintenance Guide for information on the use
of this switch.
Accessing DIMM Sockets on the Memory
Board
1. Remove the memory board as shown in Figure 4-5.
