4-11

ProLiant 3000 Setup and Installation Guide

Writer: Tom Erber Project: ProLiant 3000 Setup and Installation Guide Comments: 296908-002

File Name: E-CH04.DOC Last Saved On: 1/27/98 4:20 PM

COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED

For the best performance, DIMM banks should be added in the following
order:

First: Bank 3 (as shipped)

Bank 1 (system board)
Bank 4 (memory board)
Bank 2 (system board)
Bank 5 (memory board)

Last:

Bank 6 (memory board)

Accessing the Drive Cage Back Plane

These instructions cover the removal of the hot-plug SCSI drive and removable
media cage, removal of the Simplex Enable board, and installation of the
Duplex Enable board. This procedure enables controller duplexing of the
internal SCSI drives. Refer to the Compaq ProLiant 3000 Cabling Guidelines
Reference Guide for more information on configurating duplex and simplex
modes.

1. Remove the side panel as shown in Figure 4-1.
