Navigation buttons – Compaq PROLIANT 3000 User Manual
Page 111
6-3
ProLiant 3000 Setup and Installation Guide
Writer: Tom Erber Project: ProLiant 3000 Setup and Installation Guide Comments: 296908-002
File Name: G-CH06.DOC Last Saved On: 1/27/98 4:23 PM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Navigation Buttons
To navigate through the menus, use the four buttons shown in Figure 6-2. The
Up and Down arrow keys (
and ) allow you to move through the menu
screens and choose menu items. The right button (
) acts as an Enter key and
allows you to travel down through the menus. The left button (
) acts as an
Escape key and allows you to travel back up the menu.
1
2
3
4
ESC
Figure 6-2. Integrated Management Display buttons
