Page Manual MSC-64 6
1 Introduction
1.1 Identification and Scope
This document describes the system design for a CANopen Gateway (CGM85) and up to 64
Load Cell Digitizing Module (LDM88.x) using the Flintec backplane system. It describes the
functionality of the backplane, the protocol used on the backplane and the CANopen profile
used to access the LDM88 modules via the CGM85 Gateway. It specifies the protocols and
logical format of the messages between the CANopen and the local backplane system.
1.2 Purpose
The purpose of this document is to specify functionality and performance of the Gateway and
the Load Cell Digitizing Modules (LDM88) with the available firmware versions (standard
88.183, filling 88.184, loss in weight 88.185).
1.3 Acronyms and Definitions
1.3.1 Acronyms
This section includes a list of all abbreviations and acronyms used throughout the document
in alphabetical order.
CAN Controller Area Network
CANopen A higher layer protocol using the CAN.
FAT Factory Acceptance Test – the preliminary test
Function A software entity that encapsulates some computations and can be used
without worrying about its implementation
PDO Process Data Object
Process
A software entity that executes a computational entity, including modules
and functions.
RPDO Receive PDO
SAT Site Acceptance Test – the final test on site.
SDO Service Data Object
TPDO Transmit PDO
